Danfoss VLT AutomationDrive FC 300 Programming Guide

6-46 Term. X30/12 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s]
A 1
st
order digital low pass filter time constant for suppressing electrical noise on terminal X30/12.
Par. 6-46
Term. X30/12 Filter Time Constant cannot be changed while the motor is running.
3.8.7 6-5* Analog Output 1
Parameters for configuring the scaling and limits for analog output 1, i.e. Terminal 42. Analog outputs are current outputs: 0/4 – 20 mA. Common terminal
(terminal 39) is the same terminal and has the same electrical potential for analog common and digital common connection. Resolution on analog output
is 12 bit.
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output. Depending on the selection the
output is either a 0-20 mA or 4-20 mA output. The current value can be read out in LCP in
par. 16-65
Analog Output 42 [mA] .
[0] * No operation When no signal on the analog output.
[52] MCO 0-20mA
[53] MCO 4-20mA
[100] Output frequency 0 Hz = 0 mA; 100 Hz = 20 mA.
[101] Reference Par. 3-00
Reference Range [Min - Max] 0% = 0 mA; 100% = 20 mA
Par. 3-00
Reference Range [-Max - Max] -100% = 0 mA; 0% = 10 mA; +100% = 20 mA
[102] Feedback
[103] Motor current Value is taken from par. 16-37
Inv. Max. Current . Inverter max. current (160% current) is equal to
20 mA.
Example: Inverter norm current (11 kW) = 24 A. 160 % = 38.4 A. Motor norm current = 22 A Read-
out 11.46 mA.
20 mA x 22 A
38.4 A
= 11.46 mA
In case the norm motor current is equal to 20 mA, the output setting of par. 6-52 Terminal 42 Output
Max Scale
is:
I
VLT
Max
x 100
I
Motor
Norm
=
38.4 x 100
22
=175%
[104] Torque rel to limit The torque setting is related to setting in par. 4-16 Torque Limit Motor Mode
[105] Torq relate to rated The torque is related to the motor torque setting.
[106] Power Taken from par. 1-20
Motor Power [kW] .
[107] Speed Taken from par. 3-03
Maximum Reference . 20 mA = value in par. 3-03 Maximum Reference
[108] Torque Torque reference related to 160% torque.
[109] Max Out Freq In relation to par. 4-19
Max Output Frequency .
[113] PID Clamped Output
[119] Torque % lim
[130] Output freq. 4-20mA 0 Hz = 4 mA, 100 Hz = 20 mA
[131] Reference 4-20mA Par. 3-00
Reference Range [Min-Max] 0% = 4 mA; 100% = 20 mA
Par. 3-00
Reference Range [-Max-Max] -100% = 4mA; 0% = 12 mA; +100% = 20 mA
[132] Feedback 4-20mA
3 Parameter descriptions FC 300 Programming Guide
120 MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
