3.8.5 6-3* Analog Input 3 MCB 101
Parameter group for configuring the scale and limits for analog input 3 (X30/11) placed on option module MCB 101.
6-30 Terminal X30/11 Low Voltage
Range: Function:
0.07 V* [Application dependant] Sets the analog input scaling value to correspond to the low reference/feedback value (set in
par. 6-34
Term. X30/11 Low Ref./Feedb. Value ).
6-31 Terminal X30/11 High Voltage
Range: Function:
10.00 V* [Application dependant] Sets the analog input scaling value to correspond to the high reference/feedback value (set in
par. 6-35
Term. X30/11 High Ref./Feedb. Value ).
6-34 Term. X30/11 Low Ref./Feedb. Value
Range: Function:
0.000 N/A* [-999999.999 - 999999.999 N/A] Sets the analog input scaling value to correspond to the low voltage value (set in par. 6-30 Terminal
X30/11 Low Voltage
).
6-35 Term. X30/11 High Ref./Feedb. Value
Range: Function:
100.000 N/
A*
[-999999.999 - 999999.999 N/A] Sets the analog input scaling value to correspond to the high voltage value (set in par. 6-31 Terminal
X30/11 High Voltage
).
6-36 Term. X30/11 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s]
A 1
st
order digital low pass filter time constant for suppressing electrical noise on terminal X30/11.
Par. 6-36
Term. X30/11 Filter Time Constant cannot be changed while the motor is running.
3.8.6 6-4* Analog Input 4 MCB 101
Parameter group for configuring the scale and limits for analog input 4 (X30/12) placed on option module MCB 101.
6-40 Terminal X30/12 Low Voltage
Range: Function:
0.07 V* [Application dependant] Sets the analog input scaling value to correspond to the low reference/feedback value set in
par. 6-44
Term. X30/12 Low Ref./Feedb. Value .
6-41 Terminal X30/12 High Voltage
Range: Function:
10.00 V* [Application dependant] Sets the analog input scaling value to correspond to the high reference/feedback value set in
par. 6-45
Term. X30/12 High Ref./Feedb. Value .
6-44 Term. X30/12 Low Ref./Feedb. Value
Range: Function:
0.000 N/A* [-999999.999 - 999999.999 N/A] Sets the analog output scaling value to correspond to the low voltage value set in par. 6-40 Terminal
X30/12 Low Voltage
.
6-45 Term. X30/12 High Ref./Feedb. Value
Range: Function:
100.000 N/
A*
[-999999.999 - 999999.999 N/A] Sets the analog input scaling value to correspond to the high voltage value set in par. 6-41 Terminal
X30/12 High Voltage
.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 119
3
