Danfoss VLT AutomationDrive FC 301 Programming Guide

Option
Name
Description
[78]
Logic rule 8
See parameter group 13-4* Logic Rules. If logic rule 8 in SLC is true, the output goes high. Oth-
erwise, it is low.
[79]
Logic rule 9
See parameter group 13-4* Logic Rules. If logic rule 9 in SLC is true, the output goes high. Oth-
erwise, it is low.
[80]
SL digital output A
See parameter 13-52 SL Controller Action. Output A is low on smart logic action [32] Set digital
out A low. Output A is high on smart logic action [38].
[81]
SL digital output B
See parameter 13-52 SL Controller Action. Output B is low on smart logic action [33] Set digital
out B low. Output B is high on smart logic action [39].
[82]
SL digital output C
See parameter 13-52 SL Controller Action. Output C is low on smart logic action [34] Set digital
out C low. Output C is high on smart logic action [40].
[83]
SL digital output D
See parameter 13-52 SL Controller 1 Action. Output D is low on smart logic action [35] Set digi-
tal out D low. Output D is high on smart logic action [41].
[84]
SL digital output E
See parameter 13-52 SL Controller Action. Output E is low on smart logic action [36] Set digital
out E low. Output E is high on smart logic action [42].
[85]
SL digital output F
See parameter 13-52 SL Controller Action. Output F is low on smart logic action [37] Set digital
out F low. Output F is high on smart logic action [43].
[90]
kWh counter pulse
[96]
Reverse after ramp
N O T I C E
This option is only available with software version 48.XX.
See the description in parameter group 5-3* Digital Outputs.
[98]
Virtual master dir.
N O T I C E
This option is only available with software version 48.XX.
See the description in parameter group 5-3* Digital Outputs.
[120]
Local ref active
Output is high when parameter 3-13 Reference Site = [2] Local or when parameter 3-13 Refer-
ence Site = [0] Linked to hand auto at the same time as the LCP is in hand-on mode.
Table 361: Local Reference Active
Reference site set in parameter 3-1 3 Reference Site
Local reference active [120]
Remote reference active [121]
Reference site: Local parameter 3-13 Reference Site [2] Local
1
0
Reference site: Remote parameter 3-13 Reference Site [1] Remote
0
1
Reference site: Linked to Hand/ Auto
Hand
1
0
Hand⇒off
1
0
Auto⇒off
0
0
Auto
0
1
AU275636650261en-000101 / 130R0334 | 213Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
