Danfoss VLT AutomationDrive FC 360 User Manual

[3423] PCD 3 Read For Application [3424] PCD 4 Read For Application
[3425] PCD 5 Read For Application
[3426] PCD 6 Read For Application
[3427] PCD 7 Read For Application
[3428] PCD 8 Read For Application
[3429] PCD 9 Read For Application [3430] PCD 10 Read For Application
[3450] Actual Position
[3456] Track Error 9-27 Parameter Edit
[0] Disabled *[1] Enabled 9-28 Process Control
[0] Disable *[1] Enable cyclic master
9-44 Fault Message Counter
0 - 65535 *0
9-52 Fault Situation Counter
0 - 1000 *0
9-53 Probus Warning Word
0 - 65535 *0
9-63 Actual Baud Rate [0] 9,6 kbit/s [1] 19,2 kbit/s [2] 93,75 kbit/s [3] 187,5 kbit/s [4] 500 kbit/s [6] 1500 kbit/s [7] 3000 kbit/s [8] 6000 kbit/s [9] 12000 kbit/s [10] 31,25 kbit/s [11] 45,45 kbit/s *[255] No baudrate found
9-65 Prole Number
0 - 0 *0
9-70 Edit Set-up [1] Set-up 1 [2] Set-up 2 *[9] Active Set-up 9-71 Probus Save Data Values *[0] O [1] Store all setups 9-72 ProbusDriveReset *[0] No action [1] Power-on reset [2] Power-on reset prep [3] Comm option reset
9-80 Dened Parameters (1)
0 - 9999 *0
9-81 Dened Parameters (2)
0 - 9999 *0
9-82 Dened Parameters (3)
0 - 9999 *0
9-83 Dened Parameters (4)
0 - 9999 *0
9-84 Dened Parameters (5)
0 - 9999 *0
9-85 Dened Parameters (6)
0 - 9999 *0
9-90 Changed Parameters (1)
0 - 9999 *0
9-91 Changed Parameters (2)
0 - 9999 *0
9-92 Changed Parameters (3)
0 - 9999 *0
9-93 Changed Parameters (4)
0 - 9999 *0
9-94 Changed Parameters (5)
0 - 9999 *0
12-** Ethernet 12-0* IP Settings 12-00 IP Address Assignment
[0] MANUAL [1] DHCP [2] BOOTP *[10] DCP [20] From node ID
12-01 IP Address
0 - 4294967295 *0
12-02 Subnet Mask
0 - 4294967295 *0
12-03 Default Gateway
0 - 4294967295 *0
12-04 DHCP Server
0 - 2147483647 *0
12-05 Lease Expires
0 - 4294967295 *0
12-06 Name Servers
0 - 4294967295 *0
12-07 Domain Name
1 - 48 *0
12-08 Host Name
1 - 48 *0
12-09 Physical Address
0 - 17 *0
12-1* Ethernet Link Parameters 12-10 Link Status *[0] No Link [1] Link 12-11 Link Duration
0 - 0 *Size related
12-12 Auto Negotiation [0] O
*[1] On 12-13 Link Speed *[0] None [1] 10 Mbps [2] 100 Mbps 12-14 Link Duplex
[0] Half Duplex *[1] Full Duplex
12-8* Other Ethernet Services 12-80 FTP Server *[0] Disabled [1] Enabled 12-81 HTTP Server
*[0] Disabled [1] Enabled 12-82 SMTP Service *[0] Disabled [1] Enabled 12-89 Transparent Socket Channel Port
0 - 65535 *4000
12-9* Advanced Ethernet Services 12-90 Cable Diagnostic *[0] Disabled [1] Enabled 12-91 Auto Cross Over
[0] Disabled *[1] Enabled 12-92 IGMP Snooping [0] Disabled *[1] Enabled 12-93 Cable Error Length
0 - 65535 *0
12-94 Broadcast Storm Protection
-1 - 20 % *-1 %
12-95 Broadcast Storm Filter
*[0] Broadcast only [1] Broadcast & Multicast 12-96 Port Cong
[0] Normal [1] Mirror Port 1 to 2
[2] Mirror Port 2 to 1
[10] Port 1 disabled [11] Port 2 disabled [254] Mirror Int. Port to 1 [255] Mirror Int. Port to 2
12-98 Interface Counters
0 - 4294967295 *4000
12-99 Media Counters
0 - 4294967295 *0
13-** Smart Logic 13-0* SLC Settings 13-00 SL Controller Mode
*[0] O
[1] On 13-01 Start Event [0] False [1] True [2] Running [3] In range [4] On reference [7] Out of current range
[8] Below I low [9] Above I high [16] Thermal warning [17] Mains out of range
[18] Reversing [19] Warning [20] Alarm (trip) [21] Alarm (trip lock)
[22] Comparator 0 [23] Comparator 1 [24] Comparator 2
[25] Comparator 3 [26] Logic rule 0 [27] Logic rule 1 [28] Logic rule 2 [29] Logic rule 3 [33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27 [36] Digital input DI29
*[39] Start command [40] Drive stopped
[42] Auto Reset Trip [50] Comparator 4
[51] Comparator 5 [60] Logic rule 4 [61] Logic rule 5 [83] Broken Belt 13-02 Stop Event
Same choices with 13-01
*[40] Drive stopped
13-03 Reset SLC *[0] Do not reset SLC
[1] Reset SLC
13-1* Comparators 13-10 Comparator Operand *[0] Disabled [1] Reference % [2] Feedback % [3] Motor speed [4] Motor Current
[6] Motor power [7] Motor voltage
[8] DC-link voltage [12] Analog input AI53
[13] Analog input AI54
[18] Pulse input FI29
[19] Pulse input FI33 [20] Alarm number [30] Counter A [31] Counter B 13-11 Comparator Operator [0] Less Than (<) *[1] Approx.Equal (~)
[2] Greater Than (>) 13-12 Comparator Value
-9999 - 9999 *0
13-2* Timers 13-20 SL Controller Timer
0 - 3600 s *0 s
13-4* Logic Rules 13-40 Logic Rule Boolean 1 *[0] False [1] True [2] Running [3] In range
[4] On reference [7] Out of current range
[8] Below I low [9] Above I high
[16] Thermal warning [17] Mains out of range
[18] Reversing
[19] Warning [20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0 [23] Comparator 1
[24] Comparator 2 [25] Comparator 3
[26] Logic rule 0 [27] Logic rule 1 [28] Logic rule 2 [29] Logic rule 3 [30] SL Time-out 0 [31] SL Time-out 1 [32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19 [35] Digital input DI27
[36] Digital input DI29 [39] Start command [40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4 [51] Comparator 5
[60] Logic rule 4 [61] Logic rule 5 [70] SL Time-out 3 [71] SL Time-out 4
[72] SL Time-out 5 [73] SL Time-out 6 [74] SL Time-out 7
[83] Broken Belt 13-41 Logic Rule Operator 1
*[0] Disabled [1] AND [2] OR [3] AND NOT [4] OR NOT [5] NOT AND
[6] NOT OR [7] NOT AND NOT [8] NOT OR NOT 13-42 Logic Rule Boolean 2
Same choices with 13-40
*[0] False 13-43 Logic Rule Operator 2
Same choices with 13-41
*[0] Disabled 13-44 Logic Rule Boolean 3
Same choices with 13-40
*[0] False
13-5* States 13-51 SL Controller Event *[0] False [1] True [2] Running [3] In range
Appendix Quick Guide
MG06A702 Danfoss A/S © 03/2017 All rights reserved. 69
9 9

Danfoss VLT AutomationDrive FC 360 Specifications

General

Category	DC Drives
Output Voltage	0 to Input Voltage
Control Method	V/f, Vector Control
Communication Protocols	Modbus RTU
Enclosure Rating	IP20
Brake chopper	Built-in
EMC	Compliant with EN 61800-3
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Ambient Temperature	-10 to +50 °C
Storage Temperature	-25 to +70 °C
Relative Humidity	5 - 95% non-condensing
Altitude	Up to 1000 m
Input Voltage	380 to 480 V
