Closed-loop quick guide
Parameter Option Default Function
Parameter 0-01 Language [0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
0 Select the language for the display.
Parameter 0-06 GridType [0] 200-240 V/50 Hz/IT-grid
[1] 200-240 V/50 Hz/Delta
[2] 200-240 V/50 Hz
[10] 380-440 V/50 Hz/IT-grid
[11] 380-440 V/50 Hz/Delta
[12] 380-440 V/50 Hz
[20] 440-480 V/50 Hz/IT-grid
[21] 440-480 V/50 Hz/Delta
[22] 440-480 V/50 Hz
[30] 525-600 V/50 Hz/IT-grid
[31] 525-600 V/50 Hz/Delta
[32] 525-600 V/50 Hz
[100] 200-240 V/60 Hz/IT-grid
[101] 200-240 V/60 Hz/Delta
[102] 200-240 V/60 Hz
[110] 380-440 V/60 Hz/IT-grid
[111] 380-440 V/60 Hz/Delta
[112] 380-440 V/60 Hz
[120] 440-480 V/60 Hz/IT-grid
[121] 440-480 V/60 Hz/Delta
[122] 440-480 V/60 Hz
[130] 525-600 V/60 Hz/IT-grid
[131] 525-600 V/60 Hz/Delta
[132] 525-600 V/60 Hz
Size related Select the operating mode for restart after
reconnection of the frequency converter to
mains voltage after power-down.
Parameter 0-60 Main Menu Password 0-999 0 Dene the password for access to the LCP.
Parameter 1-00 Conguration Mode [0] Open loop
[3] Closed loop
[0] Open loop Select closed loop.
Parameter 1-13 Compressor Selection [24] VZH028-R410A
[25] VZH035-R410A
[26] VZH044-R410A
Size related Select which compressor to use.
Parameter 3-02 Minimum Reference -4999.0 - 200 Hz 0 Hz The minimum reference is the lowest value
obtainable by summing all references.
Parameter 3-03 Maximum Reference 0 - 200 Hz 200 Hz The maximum reference is the highest value
obtainable by summing all references
Parameter 3-10 Preset Reference -100 - 100 % 0 % Set up a x setpoint preset reference [0].
Parameter 3-15 Reference 1 Source [0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
[1] Analog in 53 Select the input to be used for the reference
signal.
Parameter 3-41 Ramp 1 Ramp Up
Time
0.05-3600.0 s 30.00 s Ramp-up time from 0 to parameter 1-25 Motor
Nominal Speed.
Parameter 3-42 Ramp 1 Ramp Down
Time
0.05-3600.0 s 30.00 s Ramp-down time from nominal motor speed
to 0.
