D. Operation keys and indicator lights
13 [Hand On]: Starts the motor and enables control of the
frequency converter via the LCP.
NOTICE
[2] coast inverse is the default option for
parameter 5-12 Terminal 27 Digital Input. If there is
no 24 V supply to terminal 27, [Hand On] does not
start the motor. Connect terminal 12 to terminal 27.
14 [O/Reset]: Stops the motor (O). If in alarm mode, the
alarm is reset.
15 [Auto On]: The frequency converter is controlled either via
control terminals or serial communication.
Table 6.3 Legend to Illustration 6.1, Part III
6.3 Menus
6.3.1 Status Menu
In the Status menu, the selection options are:
•
Motor frequency [Hz], parameter 16-13 Frequency.
•
Motor current [A], parameter 16-14 Motor current.
•
Motor speed reference in percentage [%],
parameter 16-02 Reference [%].
•
Feedback, parameter 16-52 Feedback[Unit].
•
Motor power parameter 16-10 Power [kW] for kW,
parameter 16-11 Power [hp] for hp. If
parameter 0-03 Regional Settings is set to [1] North
America, motor power is shown in hp instead of
kW.
•
Custom readout parameter 16-09 Custom Readout.
6.3.2 Quick Menu
Use the Quick Menu to program the most common
functions. The Quick Menu consists of:
•
Quick guide for open-loop applications.
•
Closed-loop set-up quick guide.
•
Changes made.
•
Compressor functions.
