Danfoss VLT Compressor Drive CDS 803 - 4 How to Order; Configuration

4 How to Order
4.1 Conguration
4.1.1 Type Code String
C D S P T H
130BD938.10
X S A B CX X X X
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 302221 23 272524 26 28 29 31 373635343332 38 39
X0 D
8
3
X
X
X
X X X
X X X
Illustration 4.1 Type Code
Description Position Possible option
Product group & FC series 1–6 CDS 803
Power rating 7–10 6.0–10 kW (P6K0–P10K)
Number of phases 11 Three phases (T)
Mains voltage 11–12 T2: 200–240 V AC
T4: 380–480 V AC
Enclosure 13–15 E20: IP20/Chassis
RFI lter 16–17 H4: RFI lter class A1
Brake 18 X: No brake chopper included
Display 19 A: Alpha numeric local control panel
X: No local control panel
Coating PCB 20 X: No coated PCB
C: Coated PCB
Mains option 21 X: No mains option
Adaption 22 X: No adaption
Adaption 23 X: No adaption
Software release 24–27 SXXXX: Latest release - std. software
Software language 28 X: Standard
A options 29–30 AX: No A options
B options 31–32 BX: No B options
C0 options MCO 33–34 CX: No C options
C1 options 35 X: No C1 options
C option software 36–37 XX: No options
D options 38–39 DX: No D0 options
Table 4.1 Type Code Descriptions
