Danfoss VLT Compressor Drive CDS 803 - Ordering Numbers

4.2 Ordering Numbers
4.2.1 External RFI Filter
External lters to fulll A1 50 m/B1 20 m.
Power
size 380–480 V
[kW/(hp)]
Type A B C D E F G H I J K L1 Torque [Nm
(in-lb)]
Weight [kg
(lb)]
Ordering
number
[mm (in)]
6–7.5 (8–10) FN3258-16-45 250
(9.8)
45
(1.8)
70
(2.8)
220
(8.7)
235
(9.2)
25
(1)
4.5
(0.2)
1
(0.04)
10.6
(0.4)
M5 22.5
(0.9)
31
(1.2)
0.7–0.8
(6.2–7.1)
0.8 (1.8) 132B0245
10 (13) FN3258-30-47 270
(10.6)
50
(2)
85
(3.3)
240
(9.4)
255
(10)
30
(1.2)
5.4
(0.2)
1
(0.04)
10.6
(0.4)
M5 25
(1)
40
(1.6)
1.9–2.2
(16.8–19.5)
1.2 (2.6) 132B0246
Table 4.2 RFI Filters - Details
H
B
K
C
A
D
J
G
E
F
l
1
L
1
130BC247.10
Illustration 4.2 RFI Filter
How to Order
VLT
®
Compressor Drive CDS 803
28 Danfoss A/S © 12/2015 All rights reserved. MG18N202
