Danfoss VLT FC 103 Programming Guide

Par. No. # Parameter description Default value 4-set-up Change
during
operation
Conver-
sion
index
Type
0-79 Clock Fault [0] Disabled 1 set-up TRUE - Uint8
0-81 Working Days ExpressionLimit 1 set-up TRUE - Uint8
0-82 Additional Working Days ExpressionLimit 1 set-up TRUE 0 TimeOfDay
0-83 Additional Non-Working Days ExpressionLimit 1 set-up TRUE 0 TimeOfDay
0-89 Date and Time Readout 0 N/A All set-ups TRUE 0 VisStr[25]
Table 4.3
4.1.3 1-** Load/Motor
Par. No. # Parameter description Default value 4-set-up Change
during
operation
Conver-
sion
index
Type
1-0* General Settings
1-00 Configuration Mode ExpressionLimit All set-ups TRUE - Uint8
1-03 Torque Characteristics [0] Compressor CT All set-ups TRUE - Uint8
1-1* Motor Selection
1-10 Motor Construction [0] Asynchron All set-ups FALSE - Uint8
1-1* VVC+ PM
1-14 Damping Gain 120 % All set-ups TRUE 0 Int16
1-15 Low Speed Filter Time Const. ExpressionLimit All set-ups TRUE -2 Uint16
1-16 High Speed Filter Time Const. ExpressionLimit All set-ups TRUE -2 Uint16
1-17 Voltage filter time const. ExpressionLimit All set-ups TRUE -3 Uint16
1-2* Motor Data
1-20 Motor Power [kW] ExpressionLimit All set-ups FALSE 1 Uint32
1-21 Motor Power [HP] ExpressionLimit All set-ups FALSE -2 Uint32
1-22 Motor Voltage ExpressionLimit All set-ups FALSE 0 Uint16
1-23 Motor Frequency ExpressionLimit All set-ups FALSE 0 Uint16
1-24 Motor Current ExpressionLimit All set-ups FALSE -2 Uint32
1-25 Motor Nominal Speed ExpressionLimit All set-ups FALSE 67 Uint16
1-26 Motor Cont. Rated Torque ExpressionLimit All set-ups FALSE -1 Uint32
1-28 Motor Rotation Check [0] Off All set-ups FALSE - Uint8
1-29
Automatic Motor Adaptation
(AMA) [0] Off All set-ups FALSE - Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs) ExpressionLimit All set-ups FALSE -4 Uint32
1-31 Rotor Resistance (Rr) ExpressionLimit All set-ups FALSE -4 Uint32
1-35 Main Reactance (Xh) ExpressionLimit All set-ups FALSE -4 Uint32
1-36 Iron Loss Resistance (Rfe) ExpressionLimit All set-ups FALSE -3 Uint32
1-37 d-axis Inductance (Ld) ExpressionLimit All set-ups FALSE -6 Int32
1-39 Motor Poles ExpressionLimit All set-ups FALSE 0 Uint8
1-40 Back EMF at 1000 RPM ExpressionLimit All set-ups FALSE 0 Uint16
1-5* Load Indep. Setting
1-50
Motor Magnetisation at Zero
Speed 100 % All set-ups TRUE 0 Uint16
1-51
Min Speed Normal Magnetising
[RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-52
Min Speed Normal Magnetising
[Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-58 Flystart Test Pulses Current ExpressionLimit All set-ups FALSE 0 Uint16
1-59 Flystart Test Pulses Frequency ExpressionLimit All set-ups FALSE 0 Uint16
Parameter Lists
VLT
®
Refrigeration Drive Programming Guide
MG16H102 - VLT
®
is a registered Danfoss trademark
169
4 4
