3.13 Main Menu - Data Readouts - Group 16
16-00 Control Word
Range: Function:
0 * [0 - 65535 ] View the Control word sent from the
frequency
converter via the serial communi-
cation port in hex code.
16-01 Reference [Unit]
Range: Function:
0 ReferenceFeed-
backUnit*
[-999999 - 999999
ReferenceFeed-
backUnit]
View the present
reference value applied
on impulse or analog
basis in the unit
resulting from the
configuration selected
in 1-00 Configuration
Mode (Hz, Nm or RPM).
16-02 Reference [%]
Range: Function:
0 %* [-200 - 200
%]
View the total reference. The total
reference
is the sum of digital, analog,
preset, bus, and freeze references, plus
catch-up and slow-down.
16-03 Status Word
Range: Function:
0 * [0 - 65535 ] View the Status word sent from the frequency
converter
via the serial communication port in
hex code.
16-05 Main Actual Value [%]
Range: Function:
0 %* [-100 - 100 %] View the two-byte word sent with the
Status
word to the bus Master reporting
the Main Actual Value.
16-09 Custom Readout
Range: Function:
0 CustomRea-
doutUnit*
[-999999.99 -
999999.99
CustomRea-
doutUnit]
View the user-defined
readouts
as defined in
0-30 Custom Readout Unit,
0-31 Custom Readout Min
Value and 0-32 Custom
Readout Max Value.
3.13.1 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0 kW* [0 -
1000 kW]
Displays motor power in kW. The value shown
is calculated on the basis of the actual motor
voltage and motor current. The value is
16-10 Power [kW]
Range: Function:
filtered, and therefore approx. 30 ms may pass
from
when an input value changes to when
the data read-out values change. The
resolution of read-out value on fieldbus is in
10 W steps.
16-11 Power [hp]
Range: Function:
0 hp* [0 - 1000
hp]
View the motor power in HP. The value shown
is
calculated on the basis of the actual motor
voltage and motor current. The value is
filtered, and therefore approximately 30 ms
may pass from when an input value changes
to when the data read-out values change.
16-12 Motor Voltage
Range: Function:
0 V* [0 - 6000 V] View the motor voltage, a calculated value
used
for controlling the motor.
16-13 Frequency
Range: Function:
0 Hz* [0 - 6500 Hz] View the motor frequency, without
resonance
dampening.
16-14 Motor current
Range: Function:
0 A* [0 - 1856
A]
View the motor current measured as a mean
value,
I
RMS
. The value is filtered, and thus
approximately 30 ms may pass from when an
input value changes to when the data read-
out values change.
16-15 Frequency [%]
Range: Function:
0 %* [-100 -
100
%]
View a two-byte word reporting the actual
motor frequency (without resonance
dampening) as a percentage (scale 0000-4000
Hex) of 4-19 Max Output Frequency. Set
9-16 PCD Read Configuration index 1 to send it
with the Status Word instead of the MAV.
