Danfoss VLT FC 103 Programming Guide

22-44 Wake-up Ref./FB Difference 10 % All set-ups TRUE 0 Int8
22-45 Setpoint Boost 0 % All set-ups TRUE 0 Int8
22-46 Maximum Boost Time 60 s All set-ups TRUE 0 Uint16
22-5* End of Curve
22-50 End of Curve Function [0] Off All set-ups TRUE - Uint8
22-51 End of Curve Delay 10 s All set-ups TRUE 0 Uint16
22-6* Broken Belt Detection
22-60 Broken Belt Function [0] Off All set-ups TRUE - Uint8
22-61 Broken Belt Torque 10 % All set-ups TRUE 0 Uint8
22-62 Broken Belt Delay 10 s All set-ups TRUE 0 Uint16
22-7* Short Cycle Protection
22-75 Short Cycle Protection [0] Disabled All set-ups TRUE - Uint8
22-76 Interval between Starts 300 s All set-ups TRUE 0 Uint16
22-77 Minimum Run Time 0 s All set-ups TRUE 0 Uint16
22-78 Minimum Run Time Override [0] Disabled All set-ups FALSE - Uint8
22-79
Minimum Run Time Override
Value 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
22-8* Flow Compensation
22-80 Flow Compensation [0] Disabled All set-ups TRUE - Uint8
22-81
Square-linear Curve Approxi-
mation 100 % All set-ups TRUE 0 Uint8
22-82 Work Point Calculation [0] Disabled All set-ups TRUE - Uint8
22-83 Speed at No-Flow [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
22-84 Speed at No-Flow [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
22-85 Speed at Design Point [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
22-86 Speed at Design Point [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
22-87 Pressure at No-Flow Speed 0 N/A All set-ups TRUE -3 Int32
22-88 Pressure at Rated Speed 999999 N/A All set-ups TRUE -3 Int32
22-89 Flow at Design Point 0 N/A All set-ups TRUE -3 Int32
22-90 Flow at Rated Speed 0 N/A All set-ups TRUE -3 Int32
Table 4.19
4.1.19 23-** Time Based Funtions
Par. No. # Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
23-0* Timed Actions
23-00 ON Time ExpressionLimit 2 set-ups TRUE 0
TimeOfDay-
WoDate
23-01 ON Action [0] Disabled 2 set-ups TRUE - Uint8
23-02 OFF Time ExpressionLimit 2 set-ups TRUE 0
TimeOfDay-
WoDate
23-03 OFF Action [0] Disabled 2 set-ups TRUE - Uint8
23-04 Occurrence [0] All days 2 set-ups TRUE - Uint8
23-1* Maintenance
23-10 Maintenance Item [1] Motor bearings 1 set-up TRUE - Uint8
23-11 Maintenance Action [1] Lubricate 1 set-up TRUE - Uint8
23-12 Maintenance Time Base [0] Disabled 1 set-up TRUE - Uint8
23-13 Maintenance Time Interval 1 h 1 set-up TRUE 74 Uint32
23-14 Maintenance Date and Time ExpressionLimit 1 set-up TRUE 0 TimeOfDay
23-1* Maintenance Reset
23-15 Reset Maintenance Word [0] Do not reset All set-ups TRUE - Uint8
Parameter Lists
VLT
®
Refrigeration Drive Programming Guide
184 MG16H102 - VLT
®
is a registered Danfoss trademark
44
