2.1.11 Changing a Group of Numeric Data
Values
If
the chosen parameter represents a numeric data value,
change
the chosen data value by means of the [
◀
] [
▶
]
navigation keys as well as the [
▲
] [
▼
] navigation keys. Press
[
◀
] [
▶
] keys to move the cursor horizontally.
130BP069.10
1- 6*
113 RPM 1.78 A 1(1)
Load depen. setting
1 - 60 Low speed load
compensation
100%
Illustration 2.30
Press [
▲
] [
▼
]
keys to change the data value. [
▲
] increases
the data value, and [
▼
] decreases the data value. Place the
cursor on the value to save and press [OK].
130BP070.10
1 - 60 Low speed load
compensation
1 0%
Load depen. setting 1- 6*
729RPM 6.21A 1(1)
6
Illustration 2.31
2.1.12 Value, Step-by-Step
Certain parameters can be changed step by step or
infinitely
varying. This applies to 1-20 Motor Power [kW],
1-22 Motor Voltage and 1-23 Motor Frequency.
The parameters are changed both as a group of numeric
data values and as numeric data values infinitely varying.
2.1.13 Read-out and Programming of
Indexed
Parameters
Parameters are indexed when placed in a rolling stack.
15-30
Alarm Log: Error Code to 15-33 Alarm Log: Date and
Time contain a fault log which can be read out. Choose a
parameter, press [OK], and use the up/down navigation
keys to scroll through the value log.
Use 3-10 Preset Reference as another example:
Choose the parameter, press [OK], and use the up/down
navigation keys keys to scroll through the indexed values.
To change the parameter value, select the indexed value
and press [OK]. Change the value by using the up/down
keys. Press [OK] to accept the new setting. Press [Cancel]
to
abort. Press [Back] to leave the parameter.
2.1.14 Initialisation to Default Settings
Initialise the frequency converter to default settings in two
ways.
Recommended
initialisation (via 14-22 Operation Mode)
1.
Select 14-22 Operation Mode
2. Press [OK]
3. Select “initialisation”
4. Press [OK]
5. Cut off the mains supply and wait until the
display turns off.
6. Reconnect the mains supply - the frequency
converter is now reset.
7.
Change 14-22 Operation Mode back to Normal
Operation.
NOTE
Resets
parameters selected in Personal Menu with default
factory setting.
14-22 Operation Mode
initialises
all except
14-50 RFI Filter
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-35 Minimum Response Delay
8-36 Maximum Response Delay
8-37 Maximum Inter-Char Delay
15-00 Operating hours to 15-05 Over Volt's
15-20 Historic Log: Event to 15-22 Historic Log: Time
15-30 Alarm Log: Error Code to 15-32 Alarm Log:
Time
How to Programme
VLT
®
Refrigeration Drive Programming Guide
MG16H102 - VLT
®
is a registered Danfoss trademark
23
2 2
