Events are logged with value, and time stamp in ms. The
time interval between two events depends on how often
events occur (maximum once every scan time). Data
logging is continuous but if an alarm occurs, the log is
saved and the values can be viewed on the display. This
feature is useful, for example when carrying out service
following a trip. View the historic log contained in this
parameter via the serial communication port or via the
display.
15-20 Historic Log: Event
Array [50]
Range: Function:
0 * [0 - 255 ] View the event type of the logged events.
15-21 Historic Log: Value
Array [50]
Range: Function:
0 * [0 -
2147483647
]
View the value of the logged event.
Interpret the event values according to
this table:
Digtal input
Decimal value. See
16-60 Digital Input for
description after
converting to binary
value.
Digital output
(not
monitored
in
this SW
release)
Decimal value. See
16-66 Digital Output [bin]
for description after
converting to binary
value.
Warning word Decimal value. See
16-92
Warning Word for
description.
Alarm word Decimal value. See
16-90
Alarm Word for
description.
Status word
Decimal value. See
16-03
Status Word for
description after
converting to binary
value.
Control word
Decimal value. See
16-00
Control Word for
description.
Extended
status
word
Decimal value. See
16-94 Ext. Status Word for
description.
Table 3.16
15-22 Historic Log: Time
Array [50]
Range: Function:
0 ms* [0 - 2147483647
ms]
View the time at which the logged
event
occurred. Time is measured in
ms since frequency converter start.
The max. value corresponds to
approx. 24 days which means that the
count will restart at zero after this
time period.
15-23 Historic log: Date and Time
Array [50]
Range: Function:
Size related* [ 0 - 0 ] Array parameter; Date & Time 0 - 49: This
parameter
shows at which time the
logged event occurred.
3.12.4 15-3* Alarm Log
Parameters in this group are array parameters, where up to
10
fault logs can be viewed. [0] is the most recent logged
data, and [9] the oldest. Error codes, values, and time
stamp can be viewed for all logged data.
15-30 Alarm Log: Error Code
Array [10]
Range: Function:
0 * [0 - 255 ]
View the error code and look up its meaning in .
15-31 Alarm Log: Value
Array [10]
Range: Function:
0 * [-32767 - 32767 ] View an extra description of the error.
This
parameter is mostly used in
combination with alarm 38 ‘internal
fault’.
15-32 Alarm Log: Time
Array [10]
Range: Function:
0 s* [0 - 2147483647 s] View the time when the logged event
occurred.
Time is measured in seconds
from frequency converter start-up.
15-33 Alarm Log: Date and Time
Array [10]
Range: Function:
Size related* [ 0 - 0 ] Array parameter; Date & Time 0 - 9: This
parameter
shows at which time the
logged event occurred.
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
MG16H102 - VLT
®
is a registered Danfoss trademark
101
3 3
