8-32 Baud Rate
Option: Function:
Baud rates 9600, 19200, 38400 and 76800
baud
are valid for BACnet only.
[0] 2400 Baud
[1] 4800 Baud
[2] * 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
Default refers to the FC Protocol.
8-33 Parity / Stop Bits
Option: Function:
Parity and Stop Bits for the protocol
8-30
Protocol using the FC Port. For
some of the protocols, not all
options are visible. Default depends
on the protocol selected.
[0] * Even Parity, 1 Stop Bit
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-35 Minimum Response Delay
Range: Function:
Size related* [ 5 - 10000
ms]
Specify
the minimum delay time
between receiving a request and
transmitting a response. This is
used for overcoming modem
turnaround delays.
8-36 Maximum Response Delay
Range: Function:
Size related* [ 11
- 10001
ms]
Specify
the maximum permissible
delay time between transmitting a
request and receiving a response.
Exceeding this delay time will cause
control word time-out.
8-37 Maximum Inter-Char Delay
Range: Function:
Size related* [ 0.00 - 35.00
ms]
Specify
the maximum permissible
time interval between receipt of
two bytes. This parameter activates
time-out if transmission is
interrupted.
3.9.5 8-4* Telegram Selection
8-40 Telegram Selection
Option: Function:
Enables use of freely configurable
telegrams
or standard telegrams for
the FC port.
[1] * Standard telegram 1
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
8-45 BTM Transaction Command
Option: Function:
[0] Off
8-46 BTM Transaction Status
Option: Function:
[0] Off
[1] Transaction Started
[2] Transaction Comitting
[3] Transaction Timeout
[4] Err. Non-existing Par.
[5] Err. Par. Out of Range
8-47 BTM Timeout
Range: Function:
60 s* [0 - 360 s]
3.9.6 8-5* Digital/Bus
Parameters for configuring the control word Digital/Bus
merging.
NOTE
These
parameters are active only when 8-01 Control Site is
set to [0] Digital and control word.
8-50 Coasting Select
Option: Function:
Select control of the coasting function via the
terminals
(digital input) and/or via the bus.
[0] Digital
input
Activates Start command via a digital input.
[1] Bus Activates Start command via the serial
communication
port or fieldbus option.
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
MG16H102 - VLT
®
is a registered Danfoss trademark
81
3 3
