Danfoss VLT FC 103 Operating Instructions

N75K N90K N110 N132 N160 N200
Normal Load* NO NO NO NO NO NO
Typical Shaft output at 550 V [kW] 55 75 90 110 132 160
Typical Shaft output at 575 V [hp] 75 100 125 150 200 250
Typical Shaft ouptut at 690 V [kW] 75 90 110 132 160 200
Enclosure IP21 D1h D1h D1h D1h D1h D2h
Enclosure IP54 D1h D1h D1h D1h D1h D2h
Enclosure IP20 D3h D3h D3h D3h D3h D4h
Enclosure IP00 - - - - - -
Output current
Continuous (at 550 V) [A] 90 113 137 162 201 253
Intermittent (60 s overload) (at 550 V)[A] 99 124 151 178 221 278
Continuous (at 575/690 V) [A] 86 108 131 155 192 242
Intermittent (60 s overload) (at 575/690 V) [kVA] 95 119 144 171 211 266
Continuous kVA (at 550 V) [kVA] 86 108 131 154 191 241
Continuous kVA (at 575 V) [kVA] 86 108 130 154 191 241
Continuous kVA (at 690 V) [kVA] 103 129 157 185 229 289
Max. Input current
Continuous (at 550 V) [A] 89 110 130 158 198 245
Continuous (at 575 V) [A] 85 106 124 151 189 234
Continuous (at 690 V) [A] 87 109 128 155 197 240
Max. cable size: mains, motor and load share [mm
(AWG)]
2x95 (2x3/0)
Max. cable size: brake [mm (AWG)] 2x95 (2x3/0)
Max. external mains fuses [A] 160 315 315 315 350 350
Estimated power loss at 575 V [W] 1161 1426 1739 2099 2646 3071
Estimated power loss at 690 V [W] 1203 1476 1796 2165 2738 3172
Weight, enclosure IP21, IP54 kg (lbs.) 62 (135) 125 (275)
Weight, enclosure IP20 kg (lbs.) 62 (135) 125 (275)
Weight, enclosure IP00 kg (lbs.) -
Efficiency 0.98
Output frequency 0-590 Hz
Heat sink overtemp. trip
110 °C
Power card ambient trip
75 °C
*Normal overload=110% current for 60 s
Table 11.2 Mains Supply 3x525-690 V AC
Specifications Operating Instructions
