Danfoss VLT FC 103 Operating Instructions

N250 N315 N400 P450 P500 P560 P630
Normal Load* NO NO NO NO NO NO NO
Typical Shaft output at 550 V [kW] 200 250 315 355 400 450 500
Typical Shaft output at 575 V [hp] 300 350 400 450 500 600 650
Typical Shaft ouTput at 690 V [kW] 250 315 400 450 500 560 630
Enclosure IP21 D2h D2h D2h E1 E1 E1 E1
Enclosure IP54 D2h D2h D2h E1 E1 E1 E1
Enclosure IP20 D4h D4h D4h - - - -
Enclosure IP00 - - - E2 E2 E2 E2
Output current
Continuous (at 550 V) [A] 303 360 418 470 523 596 630
Intermittent (60 s overload) (at 550 V)[A] 333 396 460 517 575 656 693
Continuous (at 575/690 V) [A] 290 344 400 450 500 570 630
Intermittent (60 s overload) (at 575/690 V) [kVA] 319 378 440 495 550 627 693
Continuous kVA (at 550 V) [kVA] 289 343 398 448 498 568 600
Continuous kVA (at 575 V) [kVA] 289 343 398 448 498 568 627
Continuous kVA (at 690 V) [kVA] 347 411 478 538 598 681 753
Max. Input current
Continuous (at 550 V) [A] 299 355 408 453 504 574 607
Continuous (at 575 V) [A] 286 339 390 434 482 549 607
Continuous (at 690 V) [A] 296 352 400 434 482 549 607
Max. cable size: mains, motor and load share, mm
(AWG) 2x185 (2x350 mcm)
4x240
(4x500
mcm)
Max. cable size: brake, mm (AWG) 2x185 (2x350 mcm)
Max. external mains fuses [A] 400 500 550 700 700 900 900
Estimated power loss at 575 V [W] 3719 4460 5023 5323 6010 7395 8209
Estimated power loss at 690 V [W] 3848 4610 5150 5529 6239 7653 8495
Weight, enclosure IP21, IP54 kg (lbs.) 125 (275)
Weight, enclosure IP20 kg (lbs.) 125 (275) -
Weight, enclosure IP00 kg (lbs.) - 221 (487) 221 (487) 236 (520) 277 (611)
Efficiency 0.98
Output frequency [Hz] 0-590 0-525
Heatsink overtemp. trip [°C]
110 95 110
Power card ambient trip [°C]
80 85
*Normal overload=110% current for 60 s
Table 11.3 Mains Supply 3x525-690 V AC
•
The typical power loss is at nominal load conditions and expected to be within ±15% (tolerance relates to variety
in voltage and cable conditions).
•
The losses are based on the default switching frequency. The losses increase significantly at higher switching
frequencies.
