Danfoss VLT FC 302 User Manual

Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
16-6* Inputs & Outputs
16-60 Digital input 0 N/A All set-ups FALSE 0 Uint16
16-61 Terminal 53 switch setting [0] Current All set-ups FALSE - Uint8
16-62 Analog input 53 0.000 N/A All set-ups FALSE -3 Int32
16-63 Terminal 54 switch setting [0] Current All set-ups FALSE - Uint8
16-64 Analog input 54 0.000 N/A All set-ups FALSE -3 Int32
16-65 Analog output 42 [mA] 0.000 N/A All set-ups FALSE -3 Int16
16-66 Digital output [bin] 0 N/A All set-ups FALSE 0 Int16
16-67 Freq. input #29 [Hz] 0 N/A All set-ups x FALSE 0 Int32
16-68 Freq. input #33 [Hz] 0 N/A All set-ups FALSE 0 Int32
16-69 Pulse output #27 [Hz] 0 N/A All set-ups FALSE 0 Int32
16-70 Pulse output #29 [Hz] 0 N/A All set-ups x FALSE 0 Int32
16-71 Relay output [bin] 0 N/A All set-ups FALSE 0 Int16
16-72 Counter A 0 N/A All set-ups TRUE 0 Int32
16-73 Counter B 0 N/A All set-ups TRUE 0 Int32
16-74 Prec. stop counter 0 N/A All set-ups TRUE 0 Uint32
16-75 Analog in X30/11 0.000 N/A All set-ups FALSE -3 Int32
16-76 Analog in X30/12 0.000 N/A All set-ups FALSE -3 Int32
16-77 Analog out X30/8 [mA] 0.000 N/A All set-ups FALSE -3 Int16
16-78 Analog out X45/1 [mA] 0.000 N/A All set-ups FALSE -3 Int16
16-79 Analog out X45/3 [mA] 0.000 N/A All set-ups FALSE -3 Int16
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1 0 N/A All set-ups FALSE 0 V2
16-82 Fieldbus REF 1 0 N/A All set-ups FALSE 0 N2
16-84 Comm. option STW 0 N/A All set-ups FALSE 0 V2
16-85 FC port CTW 1 0 N/A All set-ups FALSE 0 V2
16-86 FC port REF 1 0 N/A All set-ups FALSE 0 N2
16-9* Diagnosis Readouts
16-90 Alarm word 0 N/A All set-ups FALSE 0 Uint32
16-91 Alarm word 2 0 N/A All set-ups FALSE 0 Uint32
16-92 Warning word 0 N/A All set-ups FALSE 0 Uint32
16-93 Warning word 2 0 N/A All set-ups FALSE 0 Uint32
16-94 Ext. status word 0 N/A All set-ups FALSE 0 Uint32
Programming Operating Instructions
MG37A202 Danfoss A/S © Rev. 2014-07-29 All rights reserved. 97
6 6

Danfoss VLT FC 302 Specifications

General

Brake Function	Built-in brake chopper in all units up to 22 kW
Output Voltage Range	0-100% of input voltage
Power Range	0.37 kW
Control Modes	VVCplus, Flux, U/f
Protection Features	Overvoltage, undervoltage, overcurrent, short circuit, overtemperature, overload
Communication Options	Modbus RTU, BACnet, Ethernet/IP, Profinet, Profibus, CANopen, DeviceNet
Ambient Temperature Range	-10°C to +50°C (derating above +40°C)
Enclosure Rating	IP20, IP21, IP55
Cooling Method	Air-cooled
Input Voltage	200-240V, 380-480V, 525-600V
