e30bc567.10
12 2 2
44 3 4
44 4 4
88 7 8
1 DC(+) plate stando
2 DC(+) plate screw
3 Midplate 1 stando
4 Midplate 1 screw
5 Midplate 2 stando
6 Midplate 2 screw
7 DC(-) plate stando
8 DC(-) plate screw
Illustration 11.17 Standard DC Cap Bank with 8 Capacitor
Layout
e30bc568.10
2 1 2
2
4 4 3
4
4 4 4
4
8 8 7
8
4 2
8 4
1 DC(+) plate stando
2 DC(+) plate screw
3 Midplate 1 stando
4 Midplate 1 screw
5 Midplate 2 stando
6 Midplate 2 screw
7 DC(-) plate stando
8 DC(-) plate screw
Illustration 11.18 Standard DC Cap Bank with 10 Capacitor
Layout
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 221
