Danfoss VLT FC Series Service Guide

e30bc571.10
2
4
4
6
6
7
6
8
2
4
3
6
5
8
2
4
4
6
2
4
4
6
6
8
1 DC(+) plate stando
2 DC(+) plate screw
3 Midplate 1 stando
4 Midplate 1 screw
5 Midplate 2 stando
6 Midplate 2 screw
7 DC(-) plate stando
8 DC(-) plate screw
Illustration 11.21 Standard DC Cap Bank 12 Capacitor Layout
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 223
11 11

Danfoss VLT FC Series Specifications

General

Category	DC Drives
Series	VLT FC Series
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Overtemperature, Motor overload
Communication Interfaces	CANopen, PROFIBUS, Ethernet
Cooling Method	liquid-cooled
Enclosure Rating	IP20, IP21, IP55
Ambient Temperature	-10°C to +40°C (14°F to 104°F) without derating
