Dimensions
CDS303 frequency converter - enclosure B4
380-480 volts – 18-22 kW - IP20 housing
200-240 volts - 15 kW - IP20 housing
525-600 volts - 18-30 kW - IP20 housing
Scale 1:1
8.5
8
8.5
15
Scale 1:1
231
200
495
518
Mounting base
595
460
242
35
Air
inlet
Air
outlet
Min 200
air space inlet
Min 200
air space outlet
31FRCC.PC.023.A8.02
