Turning the power supply ON and reading/evaluating the status with always answer disabled:
LPRINT "N"+CHR$(13) :REM Turns the power supply on
LPRINT "S1" :REM Issues the status command
LINPUT S1$ :REM Read the MPS reply
IF LEFT$(S1$,1) = CHR$(?) :REM Is it an error message reply?
GOTO ERROR_HANDLING :REM Yes then go to error module
ENDIF
J=1
DO :REM evaluate status reply
IF MID$(S1$,J,1)="!"
GOSUB STATUS(J)_ACTIVE :REM set this status bit active
ELSE
GOSUB STATUS(J)_ACTIVE :REM set this status bit inactive
ENDIF
J=J+1
UNTIL J=24
Turning the power supply ON with always answer enabled:
J=0 :ERROR$=”“
DO
J=J+1 :REM Counter for maximum attempts
LPRINT "N"+CHR$(13) :REM Turns the power supply on
LINPUT RE$ :REM Read the MPS reply with 0.1 Sec. time out
IF LEFT$(RE$,1) = CHR$(?) :REM Is it an error reply?
ERROR$=RE$ :REM Mark the error code
ELSEIF RE$=”OK” :REM Is it a good reply
BRAKE :REM then exit DO loop
ELSEIF J=6 :REM Try only six times
IF LEFT$(ERROR$,1) = CHR$(?):REM Was it error reply?
GOTO ERROR_HANDLING :REM Yes then go to error module
ELSEIF
GOTO NO_COMMUNICATION :REM Yes then go to “No answer” error module
ENDIF
ENDIF
UNTIL -1 :REM loop endless
Note: An ERROR message includes a "?BELL". (Bell = ASCII 7.)
3.3.5. Software Profile Programming (Optional)
The MPS 9700 is delivered with the software ramp profile option. With the ramp profile SW it is
possible to download and run a predefined ramp sequence that the output current must follow.
The ramp sequence can be programmed using two quite different methods.
A- Arbitrary point method;
B- Equal timeslot method.
The arbitrary point method and equal timeslot methods are both available, but only one method
can be used at a time.
