3.2.5. Control Menus.
The table below lists the standard menus. (Horizontal pop up layout)
Scroll
menu
Sub
-
menu 1
Sub
-
menu 2
Sub menu 3
Comment
SET Setting of output current
CURRENT Set output current immediately
CURRENT d
elayed
Set output current after “

”
MEM
Memory function
RCL
Reg 0

9
Recalls one memory
STO
Reg 0 9
Stores to a memory
MAX/MIN Set current to one end.
0% Set current to zero
100% Set current to max
CMD Control Command line
REM Set to Remote Control
LOC Set to Local control
ADR Select a multidrop address
INTL Display Interlocks / Status
INT Internal Interlocks
CROWBAR OFF
DC OVERCURRENT (OCP)
DC OVERVOLTAGE (OVP)
15VP OK
PHASE FAILURE
EARTH LEAKAGE FAILURE
FAN
MPS OVERTEMPERATURE
* See also the list below the
tables.
EXT External interlocks
EXTERNAL INTERLOCK 0
EXTERNAL INTERLOCK 1
EXTERNAL INTERLOCK 2
EXTERNAL INTERLOCK 3
POL Change output polarity
POS + Set polarity to +
NEG - Set polarity to -
+<>- Invert output polarity
LIMITS Value limitations
I SET Current value limitations
POS
Positive limit
NEG Negative limit
