Page 54 of 56
Appendix: 9700 mounted in rack
This is a general description which is applicable for all System 9700 racks. Pictures and layout might
therefore differ from actual supply.
The Rack can hold up to 9 System 9700 modules in total. Depending on the output current, each MPS unit
will be either a single master unit (with Display) or a master with slave units (without display) placed below
the master unit.
Picture is for indication only, and will might differ from actual supply.
