DataCard SP55 User Manual

36
SP Series Style Guide
Magnetic Stripe settings used by the printer
The following table presents technical details that apply to encoding magnetic stripe data.
IATA ABA TTS NTT Binary
Character Differential 32 48 48 0 0
Start Sentinel (SS)
(ASCII character)
% (37) ; (59) ; (59) 127 None
End Sentinel (ES)
(ASCII character)
? (63) ? (63) ? (63) 127 None
Lowest ASCII Character space
(32)
0 (48) 0 (48) (1) 0
Highest ASCII Character _ (95) ? (63) ? (63) (126) 255
Character-level parity
(VRC)
Odd Odd Odd Even None
Cumulative parity (LRC) Even Even Even Even None
Density in bits per inch 210 75 210 210 210
Data bits per character6 4478
Maximum number of
encodable characters (not
including start and end
sentinel or LRC)
76 37 104 69 33
Encoding direction SS first SS first SS first SS last SS first

DataCard SP55 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Print Capabilities	Full-color, monochrome
Card Capacity	100 cards (input hopper), 30 cards (output hopper)
Card Sizes	CR80 (85.6 mm x 54 mm / 3.375" x 2.125")
Connectivity	USB
Power Requirements	100-240 VAC, 50/60 Hz
Operating System Support	Windows 7, 8, 10
