DataCard SP55 User Manual

4
SP Series Supply e-Guide
USB cable
The USB cable must be a Type CM 30V, up to a maximum of 2 meters long. The smart card USB cable is part
number 807614-001.
Carrying case
The carrying case for an SP35, SP55, and SP60 printer is part number 553950-002.
Laminator cartridge
For the SP75 printer only, the laminator cartridge is part number 558318-999.
High-capacity output hopper
For the SP75 printer only, the optional high-capacity output hopper kit is part number 564051-001. Holds up to 100
cards.

DataCard SP55 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Print Capabilities	Full-color, monochrome
Card Capacity	100 cards (input hopper), 30 cards (output hopper)
Card Sizes	CR80 (85.6 mm x 54 mm / 3.375" x 2.125")
Connectivity	USB
Power Requirements	100-240 VAC, 50/60 Hz
Operating System Support	Windows 7, 8, 10
