DataCard SP55 User Manual

2
SP Series Supply e-Guide
Cleaning roller spindle
The cleaning roller spindle holds the replaceable cleaning sleeve. The part number is 551148-001.
Printer Guide holder
The Printer Guide holder attaches to the printer to keep the Printer Guide available to users. The part number is
558359-001.
USB data cable
SP Series printers can use a USB data cable to connect the printer to the PC.
• SP55, SP60, and SP75 printers use a USB cable with part number 807614-001.
• The SP35 printer uses a USB cable with part number 807614-002
You must provide a network data cable if you use one.

DataCard SP55 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Print Capabilities	Full-color, monochrome
Card Capacity	100 cards (input hopper), 30 cards (output hopper)
Card Sizes	CR80 (85.6 mm x 54 mm / 3.375" x 2.125")
Connectivity	USB
Power Requirements	100-240 VAC, 50/60 Hz
Operating System Support	Windows 7, 8, 10
