Datakom D-500 MK2 User Manual
4
of 1
of 1 rating
197 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
D-5
00
MK2 User Manual
Firmware V-
6.
3
- 116 -
Parameter De
fin
itio
n
Unit
Min
Max
Factory
Set
Description
J1939 Engine Brand
-
0
15
0
0:
GENERIC
1:
CUMMINS
2:
DETROIT DIE
SEL
3:
DEUTZ
4:
JOHN DEERE
5:
PERKINS
6:
VOLVO
7:
CATERPILLAR
8:
SCANIA
9:
IVECO
10:
MTU-MDEC
11:
BOSCH
12:
BAUDOUI
N
Other values:
Reserv
ed. Do not us
e.
17.3. ENGI
NE PARAMETER
S GROUP (c
o
ntinued)
115
117
Table of Contents
Table of Contents
6
Installation Instructions
11
Mounting
12
Dimensions
12
Sealing, Gasket
15
Electrical Installation
16
Terminal Descriptions
17
Battery Voltage Input
17
Ac Voltage Inputs
18
Ac Current Inputs
19
Digital Inputs
22
Analog Sender Inputs and Sender Ground
22
Charge Input Terminal
23
Magnetic Pickup Input
23
Digital Outputs
24
Mains Contactor Output
24
Generator Contactor Output
24
Input/Output Extension
25
J1939-Canbus Port
26
Usb Device Port
26
Plug-In Modules
27
Modem Plug-In
28
Gsm Modem Slot
28
Wi-Fi SLOT
29
Ethernet Slot
30
Slot
31
Synchronization Plug-In
32
Analog Avr Control Output
32
Analog Governor Control Output
32
Datalink-Canbus Port
33
Analog Load Share Signal
34
Analog Plug-In
34
Analog I/O Extension Slot
34
Mains Ct Inputs Slot
35
Communication Slot
36
Ethernet Port
36
Usb Host Port
37
Port
38
Topologies
39
Selecting the Topology
39
Phase, 4 Wire, Star
40
Phase, 3 Wire, Delta
40
Phase, 4 Wire, Delta
41
Phase, 3 Wire, Delta, 2 Ct (L1-L2)
41
Phase, 3 Wire, Delta, 2 Ct (L1-L3)
42
PHASE, 3 WIRE, DELTA, 2 Cts (L1-L2)
42
PHASE, 3 WIRE, DELTA, 2 Cts (L1-L3)
43
Phase, 2 Wire
43
Functionalities
44
Ct Location Selection
44
Synchronization Functionality
45
Mains Synchronization Functionality
46
Single Genset Parallel with Mains
47
Amf Functionality
48
Ats Functionality
48
Remote Start Functionality
49
Engine Controller Functionality
50
Remote Display Unit Functionality
51
400Hz Operation
52
Connection Diagrams
53
Genset Synchronization Functionality
53
Mains Synchronization Functionality
54
Amf Functionality
56
Ats Functionality
57
Remote Start Functionality
58
Engine Control Functionality
59
Remote Display Panel Functionality
60
Terminal Description
61
Technical Specifications
66
Description of Controls
67
Front Panel Functionality
67
Pushbutton Functions
68
Display Screen Organization
70
Automatic Display Scroll
71
Measured Parameters
73
Led Lamps
74
Waveform Display & Harmonic Analysis
75
Displaying Event Logs
77
Statistical Counters
79
Fuel Filling Counter
79
Fuel Consumption Monitoring
80
Operation of the Unit
81
Quick Start Guide
81
Stop Mode
81
Auto Mode
82
Run Mode, Manual Control
83
Test Mode
84
Protections and Alarms
85
Disabling All Protections
86
Service Request Alarm
86
Shutdown Alarms
87
Loaddump Alarms
88
Warnings
90
Non-Visual Warnings
92
Programming
93
Resetting to Factory Defaults
93
Entering the Programming Mode
94
Navigating between Menus
95
Modifying Parameter Value
96
Programming Mode Exit
97
Program Parameter List
98
Controller Configuration Group
98
Electrical Parameters Group
104
Engine Parameters Group
111
Adjust Date and Time
119
Weekly Operation Schedule
120
Exerciser Schedule
121
Sender Configuration
122
Digital Input Configuration
124
Output Configuration
126
Site ID String
128
Engine Serial Number
128
Modem1-2/Sms1-2-3-4 Telephone Numbers
128
Gsm Modem Parameters
129
Ethernet Parameters
131
Sntp Parameters
132
Wi-Fi PARAMETERS
132
Synchronization Parameters
133
Ethernet Configuration
140
Wi-Fi CONFIGURATION
141
Gsm Configuration
142
Crank Cutting
143
Overcurrent Protection (Idmt)
144
Motorized Circuit Breaker Control
146
Auto Learning
148
Speed & Voltage Up/Down Relay Outputs
151
Speed Up/Down Control
151
Voltage Up/Down Control
151
J1939 Canbus Engine Support
152
Gps Support
156
Sms Commands
158
Load Transfer Modes
160
Transfer with Interruption
160
Uninterrupted Transfer
161
Soft Transfer
162
Load Sharing
163
Digital Load Sharing (Datalink)
164
Analog Load Sharing
165
Droop Mode Operation
166
Peak Lopping
167
Power Export to Mains
168
Distributed Power Export to Mains
169
Peak Lopping with Genset Priority
170
Protection Functions Paralleling with Mains
171
ROCOF FUNCTION (Rate of Change of Frequency)
171
Vector Shift Function
171
Over/Under Frequency Function
172
Over/Under Voltage Function
172
Mains Reverse Power Function
172
Frequency Function
172
Data Recording
173
Data Recording Media
173
Directory Structure
174
Understanding the Csv Format
174
Recorded Data List, Record Period
175
Software Features
176
Load Shedding / Dummy Load
176
Load Add / Substract
177
Five Step Load Management
178
Remote Start Operation
179
Disable Auto Start, Simulate Mains
179
Battery Charging Operation, Delayed Simulate Mains
180
Dual Genset Mutual Standby Operation
181
Multiple Voltage and Frequency
182
Single Phase Operation
182
External Control of the Unit
182
Automatic Exerciser
183
Weekly Operation Scheduler
183
Engine Heating Operation
184
Engine Idle Speed Operati̇on
184
Engine Block Heater
184
Fuel Pump Control
185
Gas Engine Fuel Solenoid Control
185
Pre-Transfer Signal
185
Charging the Engine Battery
186
Externally Controlled Digital Outputs
186
Combat Mode
186
Resetting the Controller
187
Automatic Connection Topology Determination
187
Zero Power at Rest
188
Modbus Communications
189
Parameters Required for Rs-485 Modbus Operation
190
Parameters Required for Modbus-Tcp/Ip Via Ethernet
190
Data Formats
190
Snmp Communications
193
Parameters Required for Snmp Via Ethernet
194
Snmp Trap Messages
194
Declaration of Conformity
195
Maintenance
195
Disposal of the Unit
195
Rohs Compliance
195
Troubleshooting Guide
196
4
Based on 1 rating
Ask a question
Give review
