D-5
00
MK2 User Manual
Firmware V-
6.
3
-
36
-
Description:
IEEE802.3 complia
nt, 100 Bas
e-TX RJ45 ethern
et port with indicating
leds
Data rate:
100 Mbits/s, auto d
etecting
Connector:
RJ45
Cable type:
CAT5 or CAT6
Isolation:
1500 VAC, 1 minute
Max distance:
100m with CAT5 or CAT6
cable
Functionality:
Embedded TCP/IP,
Web Server, We
b Client, SMT
P, e-mail, SNM
P,
Modbus TCP_IP
ST
ANDARD ETHERNET CABLE
LED FUNCTIONS:
GREEN:
This led turns
on when
the ethernet link is es
tablished (c
onnector inserted)
YELLOW:
This led
blinks when data
transfer occurs
in
wards or outwards.
Periodic
blinking will witness
data flow.
4.4.1. ETHER
NET PORT
4.4. COMMUN
ICATION S
LOT
Ethernet
Connector
35
37
