D-500 MK2 User Manual Firmware V-6.3
- 66 -
Alternator voltage: 0 to 300 V-AC (Ph-N)
Alternator frequency: 0-600 Hz.
Mains (Busbar) voltage: 0 to 300 V-AC (Ph-N)
Mains (Busbar) frequency: 0-600 Hz.
Topology: 1-2-3 phases, with or without neutral
DC Supply Range: 8.0 to 36.0 V-DC.
DC power consumption:
300 mA-DC typical @12V-DC
150 mA-DC typical @24V-DC
600 mA-DC max. @12V-DC
300 mA-DC max. @24V-DC
V-A-cos Accuracy: 0.5% + 1 digit
KW-kVA-kVAr Accuracy: 1.0% + 1 digit
CT Range: 5/5A to 5000/5A
VT Range: 0.1/1 to 6500 / 1
kW Range: 0.1kW to 65000 kW
Current Inputs: from current transformers. ../5A.
Digital inputs: input voltage 0 to 36 V-DC.
Analog input range: 0-5000 ohms.
Digital Outputs: Protected mosfet semiconductor outputs, rated 1Amp@28V-DC
Cranking dropouts: survives 0V for 100ms.
Magnetic pickup voltage: 0.5 to 30VAC.
Magnetic pickup frequency: 0 to 10000 Hz.
GOV Control Output: 0-10V-DC
AVR Control Output: ±3V-DC, fully isolated
Charge Alternator Excitation: 2W.
Display Screen: 2.9”, 128x64 pixels
Ethernet Port: 100 Mbits
USB Device: USB 2.0 Full speed
USB Host: USB 2.0 Full speed
RS-485 Port: selectable baud rate
Data Link Port: Fully Isolated CANBUS
Operating temperature: -20°C to 70°C (-4 to +158 °F)
Storage temperature: -40°C to 80°C (-40 to +176°F)
Maximum humidity: 95% non-condensing.
IP Protection: IP54 from front panel, IP30 from the rear.
Dimensions: 200 x 148 x 46mm (WxHxD)
Panel Cut-out Dimensions: 176 x 121 mm minimum.
Weight: -----
Case Material: High Temperature, non-flammable ABS/PC
Mounting: Front panel mounted with rear retaining plastic brackets.
EU Directives Conformity
-2014/35/EC (low voltage)
-2014/30/EC (electro-magnetic compatibility)
Norms of reference:
EN 61010 (safety requirements)
EN 61326 (EMC requirements)
UL / CSA Conformity:
-UL 6200, Controls for Stationary Engine Driven Assemblies (Certificate # - 20140725-E314374)
CSA Compatibility:
-CAN/CSA C22.2 No. 14-13 – Industrial Control Equipment
