Datakom D-500 MK2 - Output Terminal Details; Digital Outputs and Contactor Outputs

D-500 MK2 User Manual Firmware V-6.3
- 24 -
The unit offers 6 digital outputs with programmable function, selectable from list.
Structure:
Negative pulling protected semiconductor output. One terminal is
connected to battery negative.
Max continuous current:
1.0 ADC
Max switching voltage:
33 VDC
Overvoltage protection:
40 VDC
Short circuit protection:
> 1.7 ADC
Reverse voltage
protection:
500 VDC
Structure:
Relay output, normally closed contact. One terminal is internally
connected to mains phase L1 input.
Max switching current:
12A @250VAC
Max switching voltage:
440VAC
Max switching power:
3000VA
Structure:
Relay output, normally open contact. One terminal is internally
connected to genset phase L1 input.
Max switching current:
16A @250VAC
Max switching voltage:
440VAC
Max switching power:
4000VA
3.10. GENERATOR CONTACTOR OUTPUT
3.9. MAINS CONTACTOR OUTPUT
3.8. DIGITAL OUTPUTS
