GENERAL FEATURES
3
1
1.3 AVAILABLE MODELS
The DS2400 scanner is available in versions that differ in regard to the following
parameters:
• Reading range
• Serial interfaces
• Linear or raster reading
• Connections
The following models are therefore available:
DS2400 - X X X X
Reading Range
1 = Medium range
2 = Long range
Serial Communication Interface
0 = RS232 main + RS232 aux
1 = RS485 main + RS232 aux
Connections
0 = Connector
1 = Junction Box
Linear/Raster
0 = Linear
1 = Raster
The following tables display each version’s reading performance.
Version Max Code Resolution Speed
mm (mils) scans/s
1XXX 0.25 (10) 400 to 1000
2XXX 0.35 (14) 400 to 1000
Version Reading Distance
1XXX 100 mm (4 in) - 440 mm (17 in) on 0.50 mm (20 mils) codes
2XXX 200 mm (8 in) - 600 mm (23.5 in) on 0.50 mm (20 mils) codes
See reading diagrams in par. 3.4 for further details.
