DS2400-1XXX DS2400-2XXX
ELECTRICAL FEATURES
Input Power
Supply voltage 10 to 30 Vdc
Power consumption max. 5 W
Serial Interfaces
(depends on model)
Main RS232; RS485 Full-duplex / Half-duplex; 20 mA C.L.
(20 mA C.L. only with INT-22 accessory)
Auxiliary RS232
Baud Rates 150 to 115200
Inputs
External Trigger (optocoupled NPN or PNP)
Voltage max. 30 Vdc
Input current max. 25 mA
Outputs
OUT1, OUT2 (optocoupled)
V
CE
max. 40 Vdc
Collector current max. 40 mA continuous; 130 mA pulsed
V
CE
saturation 1V at 10 mA max.
Power dissipation max.
90 mW at 40 °C (Ambient temp.)
OPTICAL FEATURES
Light source Semiconductor laser diode
Wave length
(Note 1)
630 to 680 nm
Safety class Class 2 - IEC 825-1; Class II - CDRH
READING FEATURES
(Note 2)
Scan rate software programmable (400 to 1000 scans/sec)
Aperture angle 50°
Maximum Reading distance 440 mm (17.3 inch) 600 mm (23.6 inch)
Maximum resolution 0.25 mm (10 mils) 0.35 mm (14 mils)
USER INTERFACE
LED indicators Laser ON, Good Read, External Trigger,
Data TX / power ON
