Product Reference Guide 393
Appendix E
Handheld Data Format
Requirements
This appendix provides application notes to describe the general format of
data that can be accepted by the scanner through the auxilliary port as
transmitted from a handheld scanner.
Handheld Data Format Requirements General
• 9600 bps, 8 data bits, 2 stop bits, no parity.
• RTS is used to "bracket" the data received from the handheld: RTS
must be asserted high during data transmission, and de-asserted
after label transmission is complete. No other flow control mecha-
nisms are required or supported. The de-assertion of the RTS signal
must occur no later than 50 milliseconds from the complete trans-
mission of the last character of the transmitted data.
• The time between character transmission can be no longer than 50
milliseconds.
• Symbologies requiring fixed lengths (UPC/EAN) will enforce length
requirements for validation of the label.
• Handheld scanner will be required to transmit start and stop charac-
ters for Codabar and Code 39 labels.
• Appropriate industrial length requirements will be enforced (if con-
figured) for validation of the label.
• Maximum label lengths will be enforced for label validation (i.e.
labels longer than the maximum label size will not be validated).
• Standard Datalogic formats generally use a single prefix character.
The specific formats are provided below.
