Datalogic MAGELLAN 8500 User Manual

Product Reference Guide 2-15
Figure 2-8. Models 8501 and 8502 Long Scanner or Scanning-Scale Cutout Dimensions
Model 8501
& Model 8502
Dimensions
Model 8501
& Model 8502
Cutout
Model 8501
& Model 8502
Supports
26 lb.
(11.7kg)
Scanner/Scale
Weight
22 lb.
(10kg)
Scanner
Weight (w/o scale)
11.5"
(29.21cm)
SCANNER
11.1"
(28.19cm)
PLATTER
11.25"
(28.58cm)
20.0"
(50.8cm)
5.0" (12.7cm)
7.0" (17.78cm)
12.0"
(30.5cm)
8.9"
(22.60cm)
Window
6.95"
(17.65cm)
20.125"
(51.12cm)
0.75"
(1.905cm)
18.625"
(47.308cm)
Rail
Rail
(Center Line)
11.625"
(29.53cm)
0.75"
(1.905cm)
Max. Radius = 0.25"
(0.635cm) 4x
20.125" ±0.06"
(51.2 ±0.15 cm)
18.625" ± .060"
(47.3 ±0.15 cm)
0.375" ± .030"
(0.952 ±0.07 cm)
0.375" ± .030"
(0.952 ±0.07 cm)
If leveling feet are needed
for models 8501 and 8502,
use the placement shown here,
represented with plus signs (+).
3.06" ± .006"
(7.77 ±0.15 cm)
3.06" ± .006"
(7.77 ±0.15 cm)
0.75"
(1.9 cm)
1.5"
(3.8 cm)
0.75"± .060"
(1.9 ±0.15 cm)
0.75"± .060"
(1.9 ±0.15 cm)
4.0"
(10.2 cm)
0.375" ± 0.03" (.95 ±.08 cm)
Liquid
Drainage
Liquid
Drainage
