2-14 Magellan
®
8500 Scanner
Refer to the appropriate drawing (Figure 2-7, Model 8500; Figure 2-8,
Models 8501 and 8502) for dimensional information on the model you’ll
be installing.
Figure 2-7. Model 8500 (Short Scanner) Cutout Dimensions
Model 8500
Dimensions
Model 8500
Cutout
Model 8500
Supports
22 lb.
(10kg)
Scanner Weight
11.5"
(29.21cm)
SCANNER
11.1"
(28.19cm)
PLATTER
7.75"
(19.69cm)
16.5"
41.91cm)
5.0" (12.7cm)
7.0" (17.78cm)
12.0"
(30.5cm)
6.2"
(15.75cm)
Window
6.95"
(17.65cm)
11.625"
(29.53cm)
Max. Radius = 0.25"
(0.635cm) 4x
5" ±.062 (12.7cm)
Liquid
Drainage
Liquid
Drainage
Support Rails
16.625" ± .060"
(42.23cm)
