Description
2RIDA DBT6400
DBT 6420-HC Healtcare, cordless Bluetooth,KIT.
DBT 6420-BK Black, cordless Bluetooth,KIT.
The package includes the micro-USB cable (for reader or
base station), the pocket clip and the neck lanyard with
the reader back clip.
Top LED
Scan But-
Undo Button
Link Button
Side LEDs
Micro USB
Connector
Contacts for Base Station

Other manuals for Datalogic RIDA DBT6400

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic RIDA DBT6400 and is the answer not in the manual?

Datalogic RIDA DBT6400 Specifications

General IconGeneral
Scanner typeHandheld scanner
TypeHandheld bar code reader
Wavelength650 nm
Sensor type-
Yaw reading angle-60 - 60 °
Tilt reading angle0 - 360 °
Pitch reading angle-65 - 65 °
Linear (1D) barcodes supportedJAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range25 m
Bluetooth version4.0
Operating frequency2400 MHz
Standard interfacesBluetooth, USB
Connectivity technologyWired & Wireless
Battery life5 h
Charging time2.5 h
Battery capacity700 mAh
Power source typeBattery
Number of reads per charge3000
Number of batteries supported1
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Product colorWhite
International Protection (IP) codeIP50
Sustainability certificatesRoHS
Cables includedNo
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth42.3 mm
Width112.5 mm
Height27.5 mm
Weight85 g
