Datalogic RIDA DBT6400 Quick Reference Manual

Compatibility
12 RIDA™ DBT6400
Compatibility
Supported BT Specification
The Rida Bluetooth radio is fully compatible with the fol-
lowing Bluetooth specifications:
• Bluetooth v2.1 + EDR
•Bluetooth v3.0 + HS
•Bluetooth v4.0
•Bluetooth v4.1
For more details on connection with devices compliant
with older BT specifications, please refer to the PRG.
Device and operative system supported
In general, the Rida supports connection with devices and
Bluetooth radio stacks compliant with the above specifi-
cations (see Supported BT Specification on page 12) that
are able to support HID Host and/or SPP profile.
This is a non-exhaustive list of supported operating sys-
tems:
•iOS
•Android
• Windows (7, 8, 8.1, 10)
• Windows XP (Microsoft, Broadcom, and other com-
monly available Bluetooth stacks)
• Windows Phone 8.1 Update 2 (only for HID profile)
• Windows 10 Mobile
• Mac OS X 10.11
Note that:
• Windows XP Service Pack 2 and SP3 releases work
natively with Bluetooth v1.1, v2.0 and v2.0+EDR. To
connect with Rida, the Windows XP stack must be
replaced by a third party stack that supports newer
Bluetooth versions.
• Windows 7 works with Bluetooth v2.1+EDR. Blue-
tooth stack supports vendor-supplied additional
profiles without requiring that the Microsoft stack
be replaced. Due to the driver stack, used passkey
could be required during pairing process.

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
