Scan Modes
Quick Reference Guide 35
Power Saving
The operating time of the reader is related to the amount
of current drain from battery. There are some configura-
tion items that can reduce the power consumption and
extend battery life. For example, parameter as Audio Vol-
ume, RGB illumination for Good Read and Body, Motor
Viber settings, Green Spot feature, can impact on the
reader power consumption.
Below are some fast configuration items that could
increase the operating time of the reader:
Mode Label Description
Silent
Audio Volume off, Good
Transmission beep off,
Viber on, Body illumination
off, Good read illumination
on, Green spot on.
Moderate
power saving
Audio volume low, Good
Transmission beep on,
Viber off, Body illumination
off, Good read illumination
on, Green spot on.
Aggressive
power saving
Audio Volume off, Good
Transmission beep off,
Viber off, Body illumination
off, Good read illumination
off, Green spot on.

Other manuals for Datalogic RIDA DBT6400

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic RIDA DBT6400 and is the answer not in the manual?

Datalogic RIDA DBT6400 Specifications

General IconGeneral
Scanner typeHandheld scanner
TypeHandheld bar code reader
Wavelength650 nm
Sensor type-
Yaw reading angle-60 - 60 °
Tilt reading angle0 - 360 °
Pitch reading angle-65 - 65 °
Linear (1D) barcodes supportedJAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range25 m
Bluetooth version4.0
Operating frequency2400 MHz
Standard interfacesBluetooth, USB
Connectivity technologyWired & Wireless
Battery life5 h
Charging time2.5 h
Battery capacity700 mAh
Power source typeBattery
Number of reads per charge3000
Number of batteries supported1
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Product colorWhite
International Protection (IP) codeIP50
Sustainability certificatesRoHS
Cables includedNo
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth42.3 mm
Width112.5 mm
Height27.5 mm
Weight85 g
