Datalogic RIDA DBT6400 Quick Reference Manual

Scan Modes
Quick Reference Guide 33
Batch Mode
The reader can be programmed to work in batch mode.
The allowed batch modalities are:
• Automatic batch mode: when paired with a remote
host or base, but currently not connected (i.e. due
to an out of range event), the reader stores a label
inside the batch queue. As soon as the reader is
able to reconnect to the remote host, the batch
queue is transmitted to the host.
• Manual batch mode: the reader puts the decoded
bar code in the batch queue, independently from
the connection status. To transmit the batch queue
to a connected host, or to delete the queue, it is
possible to read the dedicated configuration label.
BATCH MODE
ENTER/EXIT PROGRAMMING MODE
 Batch Disable
Automatic Batch
Manual Batch
$CBTBM00\x0d
$CBTBM01\x0d
$CBTBM02\x0d

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
