Datalogic RIDA DBT6400 Quick Reference Manual

Technical Features
36 RIDA™ DBT6400
Technical Features
Electrical Features
Battery Type Li-Ion battery pack
Typical charge time
for full charge from
full discharge
2,5 hours when placed on Based Station or
when Host powered through the micro
USB cable connection
a
.
a. Charge times are much lower when battery is within daily typical operat-
ing condition.
Operating auton-
omy (continuous
reading)
3000 readings or 5 hour connected to a
Host.
(with aggressive power saving profile)
Max. Scan Rate 60 frames/sec.
Reading Indicators
Side and Top Illumination, Good Read Spot,
Beep, Jingle or Viber
Cradle Consump-
tion and DC input
supply range
5V +/- 10%; Power < 8W (b); Max 500mA
when in host/bus powered mode
b
.
b. Typical input current measured under factory default configuration.

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
