LED and Beeper Indications
40 RIDA™ DBT6400
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to
indicate various functions or errors on the reader. An
optional “Green Spot” also performs useful functions. The
following tables list these indications. One exception to
the behaviors listed in the tables is that the reader’s func-
tions are programmable, and so may or may not be turned
on. For example, certain indications such as the power-up
beep can be disabled using programming bar code labels.
Indication Description LED Beeper
Power-up
Beep
The reader is in the
process of power-
ing-up.
Fast RGB loop for
Top Led
Reader beeps
four times at
highest fre-
quency and vol-
ume upon
power-up.
Good Read
Beep
A label has been
successfully
scanned by the
reader.
LED behavior for
this indication is
configurable via
the feature “Good
Read: When to
Indicate” (see the
PRG for informa-
tion.)
The reader will
beep once at cur-
rent frequency,
volume, mono/
bi-tonal setting
and duration
upon a success-
ful label scan.
ROM Failure
There is an error in
the reader's soft-
ware/program-
ming
Top Led Flashes
Reader sounds
one error beep at
highest volume.
Limited
Scanning
Label Read
Indicates that a
Host connection is
not established
when the USB
interface is
enabled.
N/A
Reader 'chirps' six
times at the
highest fre-
quency and cur-
rent volume.
Reader
Active Mode
The reader is
active and ready to
scan.
Side LED is lit
steadily
a
N/A
Reader
Disabled
The reader has
been disabled by
the Host.
Top LED blinks
continuously
N/A

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
