Datalogic RIDA DBT6400 Quick Reference Manual

Programming
20 RIDA™ DBT6400
RGB LED Settings
The following configuration items specify settings for the
RGB (Red Green Blue) LEDs, which are used to indicate
Good Read and Body Illumination when Scanner is in Idle
mode.
GOOD READ LED COLOR
ENTER/EXIT PROGRAMMING MODE
GOOD READ INDICATOR = DIS-
ABLE
 GOOD READ INDICATOR =
ENABLE
GOOD READ LED COLOR = RED
 GOOD READ LED COLOR =
GREEN
GOOD READ LED COLOR = BLUE
WARNING
Depending on the setting of this
configuration parameter, the operating time
between the charges is reduced.

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
