Ergonomic Recommendations
46 RIDA™ DBT6400
Ergonomic Recommendations
Reduce or eliminate repetitive motion
Maintain a natural position
Reduce or eliminate excessive force
Keep objects that are used frequently within easy
reach
Perform tasks at correct heights
Reduce or eliminate vibration
Reduce or eliminate direct pressure
Provide adjustable workstations
Provide adequate clearance
Provide a suitable working environment
Improve work procedures.
Cleaning
Exterior surfaces and scan windows exposed to spills,
smudges or debris require periodic cleaning to ensure
best performance during scanning operations. Contacts
on the scanner and the base should also be cleaned as
needed to ensure a good connection.
Be sure to unplug the reader and base before cleaning.
Use a soft, dry cloth to clean the product. If the product is
very soiled, clean it with a soft cloth moistened with a
diluted non-aggressive cleaning solution or diluted ethyl
alcohol.
CAUTION
In order to avoid or minimize the potential risk
of ergonomic injury follow the recommenda-
tions below. Consult with your local Health &
Safety Manager to ensure that you are adhering
to your company’s safety programs to prevent
employee injury.
CAUTION
Do not use abrasive or aggressive cleansing
agents or abrasive pads to clean scan windows,
contacts or plastics.
Do not spray or pour liquids directly onto the
unit.

Other manuals for Datalogic RIDA DBT6400

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic RIDA DBT6400 and is the answer not in the manual?

Datalogic RIDA DBT6400 Specifications

General IconGeneral
Scanner typeHandheld scanner
TypeHandheld bar code reader
Wavelength650 nm
Sensor type-
Yaw reading angle-60 - 60 °
Tilt reading angle0 - 360 °
Pitch reading angle-65 - 65 °
Linear (1D) barcodes supportedJAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range25 m
Bluetooth version4.0
Operating frequency2400 MHz
Standard interfacesBluetooth, USB
Connectivity technologyWired & Wireless
Battery life5 h
Charging time2.5 h
Battery capacity700 mAh
Power source typeBattery
Number of reads per charge3000
Number of batteries supported1
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Product colorWhite
International Protection (IP) codeIP50
Sustainability certificatesRoHS
Cables includedNo
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth42.3 mm
Width112.5 mm
Height27.5 mm
Weight85 g
