Datalogic RIDA DBT6400 Quick Reference Manual

LED and Beeper Indications
Quick Reference Guide 41
a Except when in sleep mode or when a Good Read LED Duration other than
00 is selected
Programming Mode - The following indications ONLY occur
when the reader is in Programming Mode
.
Green Spot
a
flashes
momentarily
Upon successful
read of a label, the
software shall turn
the green spot on
for the time speci-
fied by the config-
ured value.
N/A N/A
Indication Description LED Beeper
Label Program-
ming Mode Entry
A valid program-
ming label has been
scanned.
Top LED
blinks con-
tinuously
Reader sounds
four low fre-
quency beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and cur-
rent volume.
Label Program-
ming Mode Accep-
tance of Partial
Label
In cases where
multiple labels
must be scanned to
program one fea-
ture, this indication
acknowledges each
portion as it is suc-
cessfully scanned.
N/A
Reader sounds
one short beep
at highest fre-
quency and cur-
rent volume.
Label Program-
ming Mode Accep-
tance of
Programming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Program-
ming Mode.
N/A
Reader sounds
one high fre-
quency beep
and 4 low fre-
quency beeps
followed by
reset beeps.
Label Program-
ming Mode Cancel
Item Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at low
frequency and
current volume.
Indication Description LED Beeper

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
