Datamax M-Class Mark II Series User Manual

Chapter 4 – Menu System 25
4
4
4
.
.
.
4
4
4
T
T
T
h
h
h
e
e
e
T
T
T
e
e
e
s
s
s
t
t
t
M
M
M
e
e
e
n
n
n
u
u
u
The Test Menu contains test and informational label selections:
 Print Quality Label
 Ribbon Test Label
 Test Label
 Validation Label
 Print Configuration
 Print Last Label
 User Defined Label
Internally generated, these labels are printed at pre-selected media type, speed, and heat
settings. Changes to these print settings can be made via the Menu System or through host
commands. When printing, use full width media to capture the entire format; otherwise, adjust
the printer and set the Label Width.

(1) Press the CANCEL KEY to stop printing.
(2) A printing delay can be set; see Print Test Rate (in Diagnostics).
4
4
4
.
.
.
5
5
5
M
M
M
e
e
e
n
n
n
u
u
u
D
D
D
e
e
e
t
t
t
a
a
a
i
i
i
l
l
l
s
s
s
Media Settings
The Media Settings menu contains label and ribbon sensing and sizing functions, as well as
printhead cleaning selections:
 Media Type
 Sensor Type
 Label Length
 Maximum Label Length *
 Paper Empty Distance *
 Label Width
 Ribbon Low Options *
 Sensor Calibration *
 Printhead Cleaning *

Items denoted with an asterisk (*) are only accessible through the Advanced Menu.
The menu selections are defined on the following pages:

Datamax M-Class Mark II Series Specifications

General

Memory	16 MB DRAM, 8 MB Flash
Operating Temperature	40°F to 95°F (4°C to 35°C)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	152 mm per second
Interfaces	USB, Serial
Optional Interfaces	Wireless 802.11b/g
Media Sensor	Reflective and Transmissive
Media Type	Labels, Tags, Tickets
Media Width	19 to 118 mm
Media Thickness	0.0025 to 0.0100 inches (0.0635 to 0.254 mm)
Ribbon Width	1.0" (25.4 mm) to 4.09 inches (27 to 104 mm)
Ribbon Length	1968' (600 m)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
Max Print Length	99 inches (2514 mm)
