The Front Panel consists of three indicator lights and three
function buttons. The functions of these lights and controls
are listed in the following sections.
Non-display printers can be configured using the DMXConfig
Utility (see Section 3.4). The printer can also be configured
using the Paper Menu Setup, (see Appendix C) for users that
do not have a host connection available.
3.1.1 Lights
Normal Mode
(Normal power-up)
STOP
Solid On:
Indicates the printer is in the ‘Paused’ state
Flashing:
(When using the Peel & Present Option) Indicates
a label is presented to the operator.
Indicates a top of form or mechanical error has occurred
Solid On:
Indicates the printer is on and ready for printing
Flashing:
Indicates the printer is receiving data from the host
ERROR
READY
 Both the
READY
and
STOP
Lights will be on during power-up initialization.

Datamax M-Class Mark II Series Specifications

General

Memory	16 MB DRAM, 8 MB Flash
Operating Temperature	40°F to 95°F (4°C to 35°C)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	152 mm per second
Interfaces	USB, Serial
Optional Interfaces	Wireless 802.11b/g
Media Sensor	Reflective and Transmissive
Media Type	Labels, Tags, Tickets
Media Width	19 to 118 mm
Media Thickness	0.0025 to 0.0100 inches (0.0635 to 0.254 mm)
Ribbon Width	1.0" (25.4 mm) to 4.09 inches (27 to 104 mm)
Ribbon Length	1968' (600 m)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
Max Print Length	99 inches (2514 mm)
