Datamax M-Class Mark II Series User Manual

Chapter 5 – Maintenance and Adjustments 51

Locking Screws

Adjustment Screws
5
5
5
.
.
.
5
5
5
P
P
P
r
r
r
i
i
i
n
n
n
t
t
t
h
h
h
e
e
e
a
a
a
d
d
d
P
P
P
r
r
r
e
e
e
s
s
s
s
s
s
u
u
u
r
r
r
e
e
e
A
A
A
d
d
d
j
j
j
u
u
u
s
s
s
t
t
t
m
m
m
e
e
e
n
n
n
t
t
t
To accommodate a variety of media types, printhead pressure is adjustable. This pressure is
factory set to work with most media types, so this adjustment should only be performed after
attempting to improve print quality through the use of the (1) heat and/or (2) print speed. When
adjusting, use only the minimum pressure necessary for better imaging. To adjust:
1. Load at least 4” (102mm) wide media and ribbon, see Section 2.2.
2. Ensure the Media Width Adjustment is set to its “left most” position, see Section 5.3.
3. Print a test label.
Non-display printers:
Simultaneously press the
PAU S E
+
FEED
buttons
Display-equipped printers:
See Section 4.4
4. Turn the Pressure Adjustment Cams counterclockwise to increase the applied pressure or
clockwise to decrease it. Make equal
adjustments to each cam to achieve even print contrast
across the media.

Pressure Adjustment
Cams

When using narrow media it is sometimes necessary to increase the pressure on the inner
(closest to centerplate) Pressure Adjustment Cam to prevent ribbon smudging.
Excessive pressure can reduce the service life of the printhead and platen roller, while unequal
pressure may cause ribbon and label tracking problems.

Datamax M-Class Mark II Series Specifications

General

Memory	16 MB DRAM, 8 MB Flash
Operating Temperature	40°F to 95°F (4°C to 35°C)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	152 mm per second
Interfaces	USB, Serial
Optional Interfaces	Wireless 802.11b/g
Media Sensor	Reflective and Transmissive
Media Type	Labels, Tags, Tickets
Media Width	19 to 118 mm
Media Thickness	0.0025 to 0.0100 inches (0.0635 to 0.254 mm)
Ribbon Width	1.0" (25.4 mm) to 4.09 inches (27 to 104 mm)
Ribbon Length	1968' (600 m)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
Max Print Length	99 inches (2514 mm)
