Chapter 4 – Menu System 28
Print Control
The Print Control menu contains printing throughput, offset and custom setup functions:
Heat
Print Speed
Feed Speed
Reverse Speed *
Slew Speed *
Row Offset
Column Offset
Present Distance
TOF Precedence
Custom Adjustments *
Items denoted with an asterisk (*) are only accessible through the Advanced Menu.
The menu selections are defined as follows:
DISPLAYED ITEM ITEM DESCRIPTION
HEAT Controls the burn time (0 - 30) of the printhead (and is equivalent to the Heat
setting in many software labeling programs), where:
10 Is the default setting.
PRINT SPEED Controls the rate of label movement during printing, where:
x.x in/sec
On M-4210 models equipped with a Media Hanger in place of a Media Hub, high print speeds may
result in printing degradation. It is recommended to set the print speed at 8ips or less.
FEED SPEED Controls the rate of label movement between printing areas, where:
x.x in/sec
REVERSE SPEED Controls the rate of label movement (2.0 - 5.0 inches per second) during backup
positioning, where:
4.0 in/sec Is the default setting.
SLEW SPEED Controls the rate of label movement (2.0 - 16.0 inches per second) between
printing areas when using the GPIO function, where:
x.x in/sec
ROW OFFSET Shifts the vertical start of print position (0 - 99.99 inches) on the label, where:
00.00 in. Is the default setting.
COLUMN OFFSET Shifts the HORIZONTAL, left-justified start of print position to the right (0-99.99
inches), without shifting the LABEL WIDTH termination point to the right, where:
00.00 in. Is the default setting.
