Datamax M-Class Mark II Series User Manual

Chapter 5 – Maintenance and Adjustments 57
File Handling Messages (Continued)
Displayed
Message
Description Possible Solution(s)
NO FILES
AVAILABLE
No associated files can
be found to perform
the requested action.
Ensure the file is present:
• Following a Print File request, this is normal when no
files are available for printing (also note that some
files will print only the file name);
• Following a Process File request, this is normal when
no files are available for processing (also note that
some files may not display); or,
• Following a Copy File request, this is normal when no
files are available for copying (also note that internal
database files cannot by copied).
NOT SUPPORTED
The file type
requested is not
supported.
Recheck the type of file requested for printing or
processing, and ensure that it matches one of the
available types for that function.
PROTECTED,
COPY FILE?
The file requested will
be copied to a
protected module.
Select YES to override protection and copy the file, or
NO to exit.
UNFORMATTED
The module is
unformatted.
Format the module.
FORMAT MODULE will erase all data in the
selected memory.

Datamax M-Class Mark II Series Specifications

General

Memory	16 MB DRAM, 8 MB Flash
Operating Temperature	40°F to 95°F (4°C to 35°C)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	152 mm per second
Interfaces	USB, Serial
Optional Interfaces	Wireless 802.11b/g
Media Sensor	Reflective and Transmissive
Media Type	Labels, Tags, Tickets
Media Width	19 to 118 mm
Media Thickness	0.0025 to 0.0100 inches (0.0635 to 0.254 mm)
Ribbon Width	1.0" (25.4 mm) to 4.09 inches (27 to 104 mm)
Ribbon Length	1968' (600 m)
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
Max Print Length	99 inches (2514 mm)
