Overview | 2
5 Workstation Series User’s Guide
Figure: 2 - 3 Media Area
.
1. Printhead
2. Upper Top-of-Form Sensor
3. Cover Latch
4. Left Media Support Bracket
5. Left Core Adapter
6. Right Core Adapter
7. Right Media Support Bracket
8. Lower Top-of-Form Sensor
9. Platen Roller
1
2
3
4
5
6
7
8
9
3
